ZyXEL Communications Intelligent Broadband Sharing Gateway P-324 User Manual
Page 38
Prestige 324 Intelligent Broadband Sharing Gateway
Hardware Installation & Initial Setup
2-5
Table 2-2 LED Descriptions
LED FUNCTION
COLOR
STATUS
MEANING
Orange
On
The Prestige is connected to a 100Mbps LAN
port(s).
Flashing
The 100M LAN port(s) is sending/receiving
packets.
WAN
WAN
Off
The WAN Link is not ready, or has failed.
Green
On
The 10M WAN Link is ok.
Flashing
The 10M WAN link is sending/receiving packets.
Orange
On
The 100M WAN Link is ok.
Flashing
The 10oM WAN link is sending/receiving
packets.
