17-10 Firmware and Configuration Maintenance
Restore Using FTP or TFTP Session Example
Figure 17-8 Restore Using FTP or TFTP Session Example
Refer to the TFTP and FTP over WAN Will Not Work When section to read about configurations that
disallow TFTP and FTP to work over WAN.
17.3.2 Restore Via Console Port
Restore configuration via console port by following the HyperTerminal procedure shown next. Procedures
using other serial communications programs should be similar.
Step 22. Display menu 24.6 and enter “y” at the following screen.
Figure 17-9 System Maintenance — Restore Configuration
Step 4. The following screen indicates that the Xmodem download has started.
Figure 17-10 System Maintenance — Starting Xmodem Download Screen
Step 5. Run the HyperTerminal program by clicking Transfer, then Receive File as shown in the
following screen.
ftp> put config.rom rom-0
200 Port command okay
150 Opening data connection for STOR rom-0
226 File received OK
221 Goodbye for writing flash
ftp: 16384 bytes sent in 0.06Seconds 273.07Kbytes/sec.
ftp>quit
Ready to restore Configuration via Xmodem.
Do you want to continue (y/n):
Starting XMODEM download (CRC mode) ...
CCCCCCCCC
