Firewall 12-11
Table 12-3 Firewall Service
FIELD DESCRIPTION
Enable Services
Blocking Select this check box to enable this feature.
Available Service This is a list of pre-defined services (ports) you may prohibit your LAN
computers from using. Select the port you want to block using the drop-down
list and click Add to add the port to the Blocked Service field.
Blocked Service This is a list of services (ports) that will be inaccessible to computers on your
LAN once you enable service blocking. Choose the IP port (TCP, UDP or
TCP/UDP) that defines your customized port from the drop down list box.
Custom Port A custom port is a service that is not available in the pre-defined Available
Services list and you must define using the next two fields.
Type Services are either TCP and/or UDP. Select from either TCP or UDP.
Port Number Enter the port number range that defines the service. For example, suppose
you want to define the Gnutella service. Select TCP type and enter a port
range from 6345-6349.
Add Select a service from the Available Services drop-down list and then click
Add to add a service to the Blocked Service.
Delete Select a service from the Blocked Services List and then click Delete to
remove this service from the list.
Clear All Click Clear All to empty the Blocked Service.
Date to Block Select everyday or the day(s) of the week to activate blocking.
Time of Day to Block
(24-Hour Format)
Select the time of day you want service blocking to take effect. Configure
blocking to take effect all day by selecting the All Day check box. You can
also configure specific times that by entering the start time in the Start (hr)
and Start (min) fields and the end time in the End (hr) and End (min) fields.
Enter times in 24-hour format, for example, "3:00pm" should be entered as
"15:00".
To save your changes to the Prestige, click Apply.
To reconfigure all the fields in this screen, click Reset.
