Prestige 324 Intelligent Broadband Sharing Gateway
NAT 11-11
Table 11-4 SUA Address Mapping Rules
FIELD DESCRIPTION EXAMPLE
Global Start IP This is the starting global IP address (IGA). If you
have a dynamic IP, enter 0.0.0.0 as the Global
Start IP. 0.0.0.0
Global End IP This is the ending global IP address (IGA). N/A
Type These are the mapping types discussed above
(see Table 11-2). Server allows you to specify
multiple servers of different types behind NAT to
this machine. See later for some examples. Server
Type These are the mapping types discussed above
(see Table 11-2). Server allows you to specify
multiple servers of different types behind NAT to
this machine. See later for some examples. Server
Once you have finished configuring a rule in this menu, press [ENTER] at the message “Press
ENTER to Confirm…” to save your configuration, or press [ESC] to cancel.
User-Defined Address Mapping Sets
Now let’s look at Option 1 in menu 15.1. Enter 1 to bring up this menu. We’ll just look at the differences
from the previous menu. Note the extra Action and Select Rule fields mean you can configure rules in this
screen. Note also that the [?] in the Set Name field means that this is a required field and you must enter a
name for the set.
If the Set Name field is left blank, the entire set will be deleted.
