GE 16-10 Call SchedulingRemote Management
16.1.1 To get to the System Status:
• Enter 24 to display Menu 24 - System Maintenance.
• In this menu, enter number 1 to open System Maintenance - Status.
• There are three commands in Menu 24.1 - System Maintenance - Status. Entering 1 drops the WAN
(PPTP/PPPoE) connection, 9 resets the counters and [ESC] takes you back to the previous screen.
The table below describes the fields present in Menu 24.1 - System Maintenance - Status. It should be
noted that these fields are READ-ONLY and are meant to be used for diagnostic purposes.
Figure 16-2 Menu 24.1 — System Maintenance — Status
The following table describes the fields present in Menu 24.1 - System Maintenance - Status.
Table 16-1 System Maintenance — Status Menu Fields
FIELD DESCRIPTION
Port The WAN or LAN port.
Status Shows the port speed and duplex setting if you’re using Ethernet
Encapsulation and Down (line is down), idle (line (ppp) idle), dial (starting to
trigger a call) and drop (dropping a call) if you’re using PPPoE Encapsulation.
TxPkts The number of transmitted packets on this port.
Menu 24.1 - System Maintenance - Status 00:15:16
Sat. Jan. 01, 2000
Port Status TxPkts RxPkts Cols Tx B/s Rx B/s Up Time
WAN Down 0 0 0 0 0 0:00:00
LAN 100M/Full 86 0 0 0 0 0:15:14
Port Ethernet Address IP Address IP Mask DHCP
WAN 00:A0:C5:01:23:46 0.0.0.0 0.0.0.0 Client
LAN 00:A0:C5:01:23:45 192.168.1.1 255.255.255.0 Server
System up Time: 0:15:19
Name:
Routing: IP
ZyNOS F/W Version: V3.60(JA.0)Xmas
Press Command:
COMMANDS: 1-Drop WAN 9-Reset Counters ESC-Exit
