20-4 Call Scheduling
20.4 Applying Schedule Sets to Remote Nodes
Once your schedule sets are configured, you must apply them to the desired remote node(s). Enter 11 from
the main menu and, using the [SPACE BAR], select PPPoE or PPTP in the Encapsulation field. Enter
your target remote node index number(s) in the Schedules field, as shown next.
Figure 20-3 Applying Schedule Sets to a Remote Node Example (PPPoE Encapsulation)
You can apply up to four schedule sets, separated by commas, for one remote node. Enter the schedule set
numbers for specific remote nodes in the Schedules field. In the examples, shown previously and next,
schedule sets 1, 3 and 4 are applied.
Menu 11.1 - Remote Node Profile
Rem Node Name= ChangeMe
Active= Yes
Encapsulation= PPPoE
Service Type= Standard
Service Name=
Outgoing:
Rem Login=
Rem Password= ********
Authen= CHAP/PAP
PPTP:
My IP Addr=
Server IP Addr=
Connection ID/Name=
Route= IP
Edit IP= No
Telco Option:
Allocated Budget(min)= 0
Period (hr)= 0
Schedules= 1,3,4
Nailed-Up Connection= No
Session Options:
Edit Filter Sets= No
Idle Timeout(sec)= 300
Press ENTER to Confirm or ESC to Cancel:
