Page 34: Chapter 2 hardware installation & initial setup
Prestige 324 Intelligent Broadband Sharing Gateway
Hardware Installation & Initial Setup
2-1
Chapter 2
Hardware Installation & Initial Setup
This chapter shows you how to connect hardware and perform the initial setup.
2.1 Front
Panel
Prestige.
Panel
CON/AUX Console/
Auxiliary
Green
On
The port is in console mode (CON/AUX switch
set to CON) and is connected to a management
computer.
2.2 Prestige Rear Panel and Connections
Figure 2-1 Prestige Rear Panel Connections
