Prestige 324 Intelligent Broadband Sharing Gateway
Remote Node Setup 9-3
Table 9-1 Fields in Menu 11.1 (Ethernet Encapsulation)
FIELD DESCRIPTION EXAMPLE
Service Name This is valid only when you have chosen PPPoE encapsulation. If you are
using PPPoE encapsulation, then type the name of your PPPoE service
here.
poellc
Outgoing
My Login This field is applicable for PPPoE encapsulation only. Enter the login
name assigned by your ISP when the Prestige calls this remote node.
Some ISPs append this field to the Service Name field above (e.g.,
jim@poellc) to access the PPPoE server.
jim
My Password Enter the password assigned by your ISP when the Prestige calls this
remote node. Valid for PPPoE encapsulation only.
*****
Server IP This field is valid for RoadRunner service type only. The Prestige will find
the RoadRunner Server IP automatically if this field is left blank. If it does
not, then you must enter the authentication server IP address here.
Route This field refers to the protocol that will be routed by your Prestige – IP is
the only option for the Prestige 10. IP
Edit IP This field leads to a “hidden” menu. Press [SPACE BAR] to select Yes
and press [ENTER] to go to Menu 11.3 - Remote Node Network Layer
Options. Yes
Session
Options
Edit Filter
sets
This field leads to another “hidden” menu. Use the [SPACE BAR] to select
Yes and press [ENTER] to open menu 11.5 to edit the filter sets. See the
Remote Node Filter section for more details. Yes
Once you have configured the Remote Node Profile Menu, press [ENTER] to return to menu 11. Press
[ENTER] at the message “Press ENTER to Confirm...” to save your configuration, or press [ESC] at any time
to cancel.
9.2.2 PPTP Encapsulation
If you change the Encapsulation to PPTP in Menu 11.1, then you will see the next screen. Please see the
appendix for information.
