9-4 Remote Node Setup
Figure 9-2 Remote Node Profile for PPTP Encapsulation
Table 9-2 Fields in Menu 11.1 (PPTP Encapsulation)
FIELD DESCRIPTION EXAMPLE
Encapsulation Press the [SPACE BAR] to choose PPTP. You must also go to
menu 11.3 to check the IP Address setting once you have
selected the encapsulation method. PPTP
My IP Addr Enter the IP address of the WAN Ethernet port. 10.0.0.140
Server IP Addr Enter the IP address of the ANT modem. 10.0.0.138
Connection
ID/Name
Enter the connection ID or connection name in the ANT. It must
follow the “c:id” and “n:name” format.
This field is optional and depends on the requirements of your
xDSL Modem.
N:My ISP
Schedules You can apply up to four schedule sets here. For more details
please refer to the Call Schedule Scheduling chapter.
Nailed-Up
Connections Use the [SPACE BAR] to select Yes if you want to make the
connection to this remote node a nailed-up connection. No
Menu 11.1 - Remote Node Profile
Rem Node Name= ChangeMe Route= IP
Active= Yes
Encapsulation= PPTP Edit IP= No
Service Type= Standard Telco Option:
Service Name=N/A Allocated Budget(min)= 0
Outgoing: Period(hr)= 0
My Login= Schedules=
My Password= ******** Nailed-up Connections= No
Authen= CHAP/PAP
PPTP : Session Options:
IP Addr= Edit Filter Sets= No
Server IP Addr= Idle Timeout(sec)= 300
Connection ID/Name=
Edit Traffic Redirect= No
Press ENTER to Confirm or ESC to Cancel:
Press Space Bar to Toggle.
