9-8 Remote Node Setup
Table 9-4 Remote Node Network Layer Options Menu Fields
FIELD DESCRIPTION EXAMPLE
IP Address
Assignment If your ISP did not assign you an explicit IP address, select
Dynamic; otherwise select Static and enter the IP address & subnet
mask in the following fields. Dynamic
Rem IP
Address If you have a Static IP Assignment, enter the IP address assigned to
you by your ISP.
Rem IP
Subnet
Mask If you have a Static IP Assignment, enter the subnet mask assigned
to you.
Gateway IP
Addr This field is applicable to Ethernet encapsulation only. Enter the
gateway IP address assigned to you if you are using a static IP
address.
My WAN
Addr If you have a Static IP Assignment, enter the gateway IP address
assigned to you.
My WAN
Addr This field is applicable to PPPoE and PPTP encapsulations only.
Some implementations, especially the UNIX derivatives, require the
WAN link to have a separate IP network number from the LAN and
each end must have a unique address within the WAN network
number. If this is the case, enter the IP address assigned to the
WAN port of your Prestige.
Note that this is the address assigned to your local Prestige, not the
remote router.
Network
Address
Translation Use the [SPACE BAR] to select either Full Feature, None or SUA
Only. See the NAT chapter for a full discussion of this feature. SUA Only
Metric This field is valid only for PPTP/PPPoE encapsulation. The metric
represents the “cost” of transmission for routing purposes. RIP
routing uses hop count as the measurement of cost, with a minimum
of 1 for directly connected networks. Enter a number that
approximates the cost for this link. The number need not be precise,
but it must be between 1 and 15. In practice, 2 or 3 is usually a good
number. 3
Private This field is valid only for PPTP/PPPoE encapsulation. This
parameter determines if the Prestige will include the route to this
remote node in its RIP broadcasts. If set to Yes, this route is kept
private and not included in RIP broadcast. If No, the route to this
remote node will be propagated to other hosts through RIP Yes
