C.22 CN6060 Internal microphone (left) connector (2-pin)

Table C-22 Internal microphone (left) connector (2-pin)

Pin No.

Signal Name

I/O

Pin No.

Signal Name

I/O

1 (IMICL-PXP) O

2 A-GND

C.23 CN6061 Internal microphone (right) connector (2-pin)

Table C-23 Internal microphone (right) connector (2-pin)

Pin No.

Signal Name

I/O

Pin No.

Signal Name

I/O

1 (IMICR-PXP) O

A-GND

C.24 J6070 External microphone connector (6-pin)

Table C-24 External microphone connector (6-pin)

Pin No.

Signal Name

I/O

Pin No.

Signal Name

I/O

1 (A-GND)

4 A-GND

2 (MICIN)

O 5 (A4R7-P4V)

3 (MICBIS-P2V) O 6 (MICBIS-P2V) O

C.25 CN6170 Speaker connector (4-pin)

Table C-25 Speaker connector (4-pin)

Pin No.

Signal Name

I/O

Pin No.

Signal Name

I/O

1 SPOTR-PXN O 2 SPOTR-PXP O

3 SPOTL-PXP

O 4 SPOTL-PXN O
