C.10 CN3010 MDC I/F connector (12-pin)
Table C-10 MDC I/F connector (12-pin)
Pin No.
Signal Name
I/O
Pin No.
Signal Name
I/O
1 GND
-
2 NC
-
3 ACZOT1-P3P I/O 4 NC
-
5 GND
-
6 E3V
-
7 ACZSY1-P3P O 8 GND
-
9 ACZIN1-E3P I/O 10
GND
-
11 ACZRS1-E3N O 12 XAZBC1-P3P O
1T
GND -
2T
GND -
3T
GND -
4T
GND -
5T
GND -
6T
GND -
C.11 CN3230 Keyboard connector (34-pin)
Table C-11 Keyboard connector (34-pin)
Pin No.
Signal Name
I/O
Pin No.
Signal Name
I/O
1
NC -
2
NC -
3
NC -
4
NC -
5
NC -
6
NC -
7 KBSC15-S3N O 8 KBSC14-S3N O
9 KBRT07-S3N O 10
KBRT06-S3N O
11 KBSC13-S3N O 12
KBSC12-S3N O
13 KBRT05-S3N O 14
KBRT04-S3N O
15 KBSC11-S3N O 16
KBSC10-S3N O
17 KBRT03-S3N O 18
KBRT02-S3N O
19 KBRT01-S3N O 20 KBSC09-S3N O
21 KBSC08-S3N O 22
KBSC07-S3N O
23 KBRT00-S3N O 24 KBSC06-S3N O
25 KBSC05-S3N O 26
KBSC04-S3N O
27 KBSC03-S3N O 28
KBSC02-S3N O
29 KBSC01-S3N O 30
KBSC00-S3N O
31 P5V
I
32 CAPLED-P5N I
33 ARWLED-P5N I
34 NUMLED-P5N I
1T
GND -
2T
GND -
