1 Hardware Overview
PORTEGE M400 Maintenance Manual (960-541) [ CONFIDENTIAL] 1-iii
Chapter 1 Contents
1.1 Features ...................................................................................................................... 1-1
1.2 2.5-inch Hard Disk Drive......................................................................................... 1-11
1.3 Optical Drive............................................................................................................ 1-14
1.3.1 DVD-ROM & CD-R/RW Drive ........................................................ 1-14
1.3.2 DVD Super Multi Drive ..................................................................... 1-16
1.3.3 DVD Super Multi Drive (Double-layer) ............................................ 1-18
1.4 Keyboard.................................................................................................................. 1-20
1.5 TFT Color Display................................................................................................... 1-21
1.5.1 LCD Module ...................................................................................... 1-21
1.5.2 FL Inverter Board............................................................................... 1-22
1.6 Power Supply ........................................................................................................... 1-23
1.7 Batteries ................................................................................................................... 1-25
1.7.1 Main Battery....................................................................................... 1-25
1.7.2 Battery Charging Control ................................................................... 1-26
1.7.3 RTC Battery ....................................................................................... 1-27
1.8 AC Adapter .............................................................................................................. 1-28
