– 7 –
Unit model Indoor RAS-M10EKCVP-E, RAS-M13EKCVP-E, RAS-M16EKCVP-E
Outdoor RAS-M14EACV-E RAS-M18EACV-E
Cooling Capacity (kW) 4.0 5.2
Cooling Capacity range (kW) 1.4 - 4.5 1.4 - 6.2
Heating Capacity (kW) – –
Heating Capacity range (kW) – –
Power supply 220~240V-1Ph-50Hz / 220V-1Ph-60Hz
Electric
charactaristics Indoor
(220V/230V/
240V) Unit model RAS-M10EKCVP-E RAS-M13EKCVP-E RAS-M16EKCVP-E(*1)
Runnning Current (A) 0.15 0.15 0.15
Power Consumption (W) 30 30 30
Power factor (%) 91/87/83 91/87/83 91/87/83
Outdoor
(220V/230V/
240V) Unit model RAS-M14EACV-E RAS-M18EACV-E
Operation mode Cooling Heating Cooling Heating
Running current (A) 4.87/4.64/4.44 – 7.12/6.80/6.50 –
Power Consumption (W) 1020 – 1540 –
Power factor (%) 95 – 98 –
Starting current (A) 5.17/4.94/4.74 7.42/7.10/6.80
COP(Cooling/Heating) 3.70/– 3.25/–
Operating noise
dB(A) Indoor
(Cooling/Heat-
ing) Unit model RAS-M10EKCVP-E RAS-M13EKCVP-E RAS-M16EKCVP-E(*1)
High 42/– 43/– 45/–
Medium 33/– 34/– 36/–
Low 27/– 27/– 29/–
Outdoor
(Cooling/Heat-
ing) Unit model RAS-M14EACV-E RAS-M18EACV-E
2 indoor units operating
46/– 48/–
Indoor unit Unit model RAS-M10EKCVP-E RAS-M13EKCVP-E RAS-M16EKCVP-E(*1)
Dimension
(mm) Hight 250 250 250
Width 790 790 790
Depth 215 215 215
Net weight (kg) 9 9 9
Fan motor output (W) 30 30 30
Air fl ow rate (m 3 /h) (Cooling/Heating) 550/– 560/– 640/–
Outdoor unit Unit model RAS-M14EACV-E RAS-M18EACV-E
Dimension
(mm) Hight 550 550
Width 780 780
Depth 290 290
Net weight (kg) 36 40
Compressor Motor output (W) 750 1100
Type Twin rotary type with DC-inverter variable speed control
Model DA111A1F-20F1 DA130A1F-25F
Fan motor output (W) 43 43
Air fl ow rate (m 3 /h) 1820 2100
Type Flare connection Flare connection
Piping connec-
tion Indoor unit Unit model RAS-M10EKCVP-E RAS-M13EKCVP-E RAS-M16EKCVP-E (*1)
Liquid side ∅ 6.35 ∅ 6.35 ∅ 6.35
Gas side ∅ 9.52 ∅ 9.52 ∅ 12.7
Outdoor unit Unit model RAS-M14EACV-E RAS-M18EACV-E
Liquid side/gas side ∅ 6.35 / 9.52 ∅ 6.35 / 9.52
Maximum length (per unit) (m) 20 20
Maximum length (total) (m) 30 30
Maximum chargeless length(total) (m) 20 20
Maximum height difference (m) 10 10
Additional refrigerant 20g/m (pipe length 21m to 30m) 20g/m (pipe length 21m to 30m)
Name of refrigerant R410A R410A
Weight (kg) 0.90 1.20
Wiring connection Power supply 3 Wires : includes earth
Interconnection 4 Wires : includes earth
Usable temperature range ( ° C) Indoor (Cooling/Heating) 21 to 32/0 to 27
Outdoor (Cooling/Heating) 5 to 43/-10 to 24
Accessory Indoor unit Unit model RAS-M10EKCVP-E RAS-M13EKCVP-E RAS-M16EKCVP-E(*1)
Installation plate 1 1 1
1 1 Wireless remote controller 1
Batteries 2 2 2
Remote control holder 1 1 1
Zeolite-plus filter 1 1 1
Plasma Pure filter 1 1 1
Remote controller
holder mounting screw
2 ( ∅ 3.1×16L) 2 ( ∅ 3.1×16L) 2 ( ∅ 3.1×16L)
Owner’s manual 1 1 1
Mounting screw 6 ( ∅ 4×25L) 6 ( ∅ 4×25L) 6 ( ∅ 4×25L)
Installation manual 1 1 1
Outdoor unit Unit model RAS-M14EACV-E RAS-M18EACV-E
Installation manual 1 1
Specifications 1 1
0 Drain nipple 0
Water-proof rubber cap 0 0
2-1-2 Specifications
Cooling-only models
• (*1) The RAS-M16EKCVP-E cannot be used in combination with the RAS-M14EACV-E.
• For performance when each indoor unit is combined with other unit, refer to the separate table.
• The specifications may be subject to change without notice for purpose of improvement.
