– 6 –
Unit model Indoor RAS-B10EKVP-E, RAS-B13EKVP-E, RAS-B16EKVP-E
Outdoor RAS-M14EAV-E RAS-M18EAV-E
Cooling Capacity (kW) 4.0 5.2
Cooling Capacity range (kW) 1.4 - 4.5 1.4 - 6.2
Heating Capacity (kW) 4.4 6.7
Heating Capacity range (kW) 0.9 - 5.2 0.9 - 8.5
Power supply 220~240V-1Ph-50Hz / 220V-1Ph-60Hz
Electric
charactaristics Indoor
(220V/230V/
240V) Unit model RAS-B10EKVP-E RAS-B13EKVP-E RAS-B16EKVP-E(*1)
Runnning Current (A) 0.15 0.15 0.15
Power Consumption (W) 30 30 30
Power factor (%) 91/87/83 91/87/83 91/87/83
Outdoor
(220V/230V/
240V) Unit model RAS-M14EAV-E RAS-M18EAV-E
Operation mode Cooling Heating Cooling Heating
Running current (A) 4.87/4.64/4.44 4.43/4.23/4.04 7.12/6.80/6.50 8.28/7.91/7.57
Power Consumption (W) 1020 950 1540 1790
Power factor (%) 95 97 98 98
Starting current (A) 5.17/4.94/4.74 7.42/7.10/6.80
COP(Cooling/Heating) 3.70/4.36 3.25/3.62
Operating noise
dB(A) Indoor
(Cooling/Heat-
ing) Unit model RAS-B10EKVP-E RAS-B13EKVP-E RAS-B16EKVP-E(*1)
High 42/43 43/44 45/45
Medium 33/34 34/35 36/36
Low 27/27 27/27 29/29
Outdoor
(Cooling/Heat-
ing) Unit model RAS-M14EAV-E RAS-M18EAV-E
2 indoor units operating
46/48 48/50
Indoor unit Unit model RAS-B10EKVP-E RAS-B13EKVP-E RAS-B16EKVP-E(*1)
Dimension
(mm) Hight 250 250 250
Width 790 790 790
Depth 215 215 215
Net weight (kg) 9 9 9
Fan motor output (W) 30 30 30
Air fl ow rate (m 3 /h) (Cooling/Heating) 550/610 560/640 640/660
Outdoor unit Unit model RAS-M14EAV-E RAS-M18EAV-E
Dimension
(mm) Hight 550 550
Width 780 780
Depth 290 290
Net weight (kg) 36 40
Compressor Motor output (W) 750 1100
Type Twin rotary type with DC-inverter variable speed control
Model DA111A1F-20F1 DA130A1F-25F
Fan motor output (W) 43 43
Air flow rate (m 3 /h) 1820 2100
Type Flare connection Flare connection
Piping connec-
tion Indoor unit Unit model RAS-B10EKVP-E RAS-B13EKVP-E RAS-B16EKVP-E (*1)
Liquid side ∅ 6.35 ∅ 6.35 ∅ 6.35
Gas side ∅ 9.52 ∅ 9.52 ∅ 12.7
Outdoor unit Unit model RAS-M14EAV-E RAS-M18EAV-E
Liquid side/gas side ∅ 6.35 / 9.52 ∅ 6.35 / 9.52
Maximum length (per unit) (m) 20 20
Maximum length (total) (m) 30 30
Maximum chargeless length(total) (m) 20 20
Maximum height difference (m) 10 10
Additional refrigerant 20g/m (pipe length 21m to 30m) 20g/m (pipe length 21m to 30m)
Name of refrigerant R410A R410A
Weight (kg) 0.90 1.20
Wiring connection Power supply 3 Wires : includes earth
Interconnection 4 Wires : includes earth
Usable temperature range ( ° C) Indoor (Cooling/Heating) 21 to 32/0 to 27
Outdoor (Cooling/Heating) 5 to 43/-10 to 24
Accessory Indoor unit Unit model RAS-B10EKVP-E RAS-B13EKVP-E RAS-B16EKVP-E(*1)
Installation plate 1 1 1
1 1 Wireless remote controller 1
Batteries 2 2 2
Remote control holder 1 1 1
Zeolite-plus filter 1 1 1
Plasma Pure filter 1 1 1
Remote controller
holder mounting screw
2 ( ∅ 3.1×16L) 2 ( ∅ 3.1×16L) 2 ( ∅ 3.1×16L)
Owner’s manual 1 1 1
Mounting screw 6 ( ∅ 4×25L) 6 ( ∅ 4×25L) 6 ( ∅ 4×25L)
Installation manual 1 1 1
Outdoor unit Unit model RAS-M14EAV-E RAS-M18EAV-E
Installation manual 1 1
Specifi cations 1 1
Drain nipple 1 1
Water-proof rubber cap 2 2
2-1-1 Specifications
Heat pump models
• (*1) The RAS-B16EKVP-E cannot be used in combination with the RAS-M14EAV-E.
• For performance when each indoor unit is combined with other unit, refer to the separate table.
• The specifications may be subject to change without notice for purpose of improvement.
