Appendix
Appendix-2
No. Remarks Specifications/Vendor Q’ty Part name
NOTE: The parts on the above table are recommended parts.
13
14
15
16
17
Power cord
Thermostat
fixing plate
PVC tube
Shield tube
Bundling tie
1
1
1
1
1
2-cores x 0.75mm² or more, H05RN-F
Material: SGCC-Z08, Board thickness: 0.8t
Inside diameter Ø8 x outside diameter Ø11 x 70 mm
Inside diameter Ø18 x outside diameter Ø26 x 70 mm
Material: Polyethylene foam
Bundling tie for securing the wires
Material: 6/6 nylon
Procured locally
Procured locally
(Drawing attached)
Procured locally
Procured locally
Procured locally
Usage
It is used for disassembling and assembling of each cabinet.
It is used for disassembling and assembling of compressor fixing nuts.
It is used to make the additional holes on the base or the side cabinet
(R).
It is used to process the side cabinet (L).
2. Required tools for installation work
No.
1
2
3
4
5
6
7
8
9
10
Part name
Plus screwdriver
Wrench
Motor drill
Faston crimping tool
Close-end connec-
tor crimping tool
Cutting plier
Stripper
Cutter knife
Insulation tape
Metal-cutting shears
Specifications
Drill diameter:
Ø3.2 and Ø5.0
Fixing jig for #250
