Dr. Rhythm Date: Dec. 27, 2002
Model: DR-3
MIDI Implementation
Version:1.00
1. RECOGNIZED RECEIVE DATA
■Channel Voice Message
●Note Off
Status Second Third
8nH kkH vvH
9nH kkH 00H
n = MIDI Channel Number: 0H–FH (ch.1–ch.16)
kk = Note Number: 00H–7FH (0–127)
vv = Velocity: 00H–7FH (0–127)
* Velocity value is not recognized.
* Not recognized in case that MIDI Channel value is “OFF” for each part.
●Note On
Status Second Third
9nH kkH vvH
n = MIDI Channel Number: 0H–FH (ch.1–ch.16)
kk = Note Number: 00H–7FH (0–127)
vv = Velocity: 01H–7FH (1–127)
* Not recognized in case that MIDI Channel value is “OFF” for each part.
* For drum part, note number of recognized data is as follows:
DRUM PERC
Pad number Note number Pad number Note number
Pad 1 36 (24H) (C2) Pad 1 62 (3EH) (D4)
Pad 2 38 (26H) (D2) Pad 2 63 (3FH) (D#4)
Pad 3 37 (25H) (C#2) Pad 3 64 (40H) (E4)
Pad 4 42 (2AH) (F#2) Pad 4 60 (3CH) (C4)
Pad 5 46 (2EH) (A#2) Pad 5 61 (3DH) (C#4)
Pad 6 53 (35H) (F3) Pad 6 39 (27H) (D#2)
Pad 7 51 (33H) (D#3) Pad 7 56 (38H) (G#3)
Pad 8 49 (31H) (C#3) Pad 8 54 (36H) (F#3)
Pad 9 48 (30H) (C3) Pad 9 69 (45H) (A4)
Pad 10 45 (2DH) (A2) Pad 10 75 (4BH) (D#5)
Pad 11 41 (29H) (F2) Pad 11 70 (46H) (A#4)
Pad 12 57 (39H) (A3) Pad 12 67 (43H) (G4)
Pad 13 58 (3AH) (A#3) Pad 13 68 (44H) (G#4)
* For the bass part, the range of note numbers are 1CH–40H (28–64, E1–E4). Though the other note numbers can be received, they are
sounded converting into the range of the note numbers E1–E4.
