ASMi-450 Control from the Control Port
4-16 ASMi-450 Installation and Operation Manual
Terminal Type
TV- 920 VT-52 VT-100 Freedom-110 Freedom-220
Clear Screen 1B2A0000 N/A 1B5B324A 1B2A0000 1B5B324A
Cursor Home 1E000000 1B480000 1B5B4800 1E000000 1B5B4800
Cursor Right 0C000000 1B430000 1B5B3143 0C000000 1B5B0143
Format DEF TERM 'terminal'
Use 1. To configure the ASMi-450 for using the control sequences corresponding to a
supported terminal, type:
DEF TERM 'terminal'
where 'terminal' stands for one of the types listed in the table above.
2. In response, you will see the new control sequences, in the format shown below:
New Control Sequences:
CLEAR SCREEN = hhhhhhhh
CURSOR HOME
= hhhhhhhh
CURSOR RIGHT = hhhhhhhh
where h indicates hexadecimal digits.
DSP ALM --------------------------------------------------------------------------------------
Purpose Display the contents of the alarm buffer. This buffer can contain up to 100 alarms.
Format DSP ALM [Option]
Use 1. To display the complete contents of the buffer, type:
DSP ALM
2. To display the complete buffer contents and then clear the type-ON alarms, type:
DSP ALM /C
3. To display the complete buffer and then clear all the stored alarms, type:
DSP ALM /CA
Display
Format The contents of the alarm buffer are displayed as a table with four columns: the alarm
number and alarm syntax (description), alarm state, and time of alarm occurrence. Each
block of alarms received from a ASMi-450 is preceded by a header. The header lists the
assigned node name and the node number of the ASMi-450 unit which sent the alarm
block, and thus it serves as an easily-identified separator between alarms transmitted by
different ASMi-450 units.
Table 4-2 lists all the alarm messages that can be displayed by the terminal.
Function
