ASMi-450 Control from the Control Port
4-8 ASMi-450 Installation and Operation Manual
Table 4-A. ASMi-450 Command Set Index
Command Purpose Options
CLR ALM Clear the alarms stored in the ASMi-450 alarm buffer /A
CLR LOOP L PORT
CLR LP L PORT
CLR LOOP R R PORT
CLR LP R R PORT
Clear user-initiated loopbacks or tests
CLR TST Clear all the user-initiated tests and loopbacks
DATE Set the date for the ASMi-450 internal clock
DEF AGENT Define the SNMP agent configuration parameters
DEF NAME Define the logical name of the ASMi-450
DEF NODE Define the node number of the ASMi-450
DEF PWD Define new password
DEF SP Define control port parameters
DEF SYS Define system parameters
DEF TERM Define the supervision terminal type and control sequences
DSP ALM Display the contents of the alarm buffer and optionally clear the buffer /C
/CA
DSP HDR TST Display hardware faults (detected during the power-on self-test, and
during normal operation)
DSP ST LINE Display status information on the HDSL lines /R
DSP ST PORT Display status information on the user's data port /R
DSP ST SYS Display system status information
EXIT End the current control session
F Select the codes for the “clear the screen”, “cursor right”, and “cursor
home” commands sent to the control terminal
HELP Displays a concise index of commands and option switches
INIT DB Load the default configuration instead of the user configuration. Table
4-3 lists default parameter values
INIT F Reset the codes for “clear the screen”, “cursor right”, and “cursor
home” to 0
LOOP L PORT
LP L PORT
LOOP R R PORT
LP R R PORT
Activate a specified user-controlled loopback or test
NODE Select an ASMi-450 before starting a management session on a
multidrop connection
PASSWORD Enter the password when prompted to type the password upon the start
of a control session
RESET Reset the ASMi-450 system
TIME Set the time of the ASMi-450 internal clock
