A.2 V.35 DCE Connector
When the ASMi-450 is ordered with an V.35 DCE interface, the physical
interface is a 34-pin female connector wired in accordance with Table A-3.
Table A-3. V.35 DCE Connector
Pin Designation
Direction
Function
A
PG
↔
Protective Ground
B
SG
↔
Signal Ground
C
RTS
To ASMi-450
Request to Send
D
CTS
From ASMi-450
Clear to Send
E
DSR
From ASMi-450
Data Set Ready
F
DCD
From ASMi-450
Data Carrier Detect
P
TDA
To ASMi-450
Transmit Data - wire A
R
RDA
From ASMi-450
Receive Data - wire A
S
TDB
To ASMi-450
Transmit Data - wire B
T
RDB
From ASMi-450
Receive Data - wire B
U
ETCA
To ASMi-450
External Transmit Clock - wire A
V
RCA
From ASMi-450
Receive Clock - wire A
W
ETCB
To ASMi-450
External Transmit Clock - wire B
X
RCB
From ASMi-450
Receive Clock - wire B
Y
TCA
From ASMi-450
Transmit Clock - wire A
Z
ERCB
To ASMi-450
External Receive Clock - wire B
AA
TCB
From ASMi-450
Transmit Clock - wire B
BB
ERCA
To ASMi-450
External Receive Clock - wire A
