Front-Panel Operating Instructions
3-14 ASMi-450 Installation and Operation Manual
Step Action Key Display
1 Bring the cursor under the top row (if not
already there)
CURSOR
2 Scroll to display the desired group of
parameters in the top row
NOTE
When the desired group of parameters
must be independently selected for each
link, the top row includes an additional
field (at the rightmost side of the top
row): this field is used to select the
desired link number. In this case, use the
CURSOR key to bring the cursor to the
rightmost field, then SCROLL to show
the desired link number.
SCROLL Second row shows the first parameter in the
selected group and its current value
3 When the second row has more than one
field, bring the cursor under the left-hand
field (parameter name) in the second row,
and then scroll to display the desired
parameter in the selected group
CURSOR
SCROLL
The second row shows the parameter name
and its current value
4 Bring the cursor under the right-hand field
(the parameter value) in the second row
CURSOR
5 Scroll to set the required value for the
displayed parameter
SCROLL The second row shows the available values
6 When the desired parameter value is
displayed, select the new parameter value
NOTE
You must press ENTER after changing
parameters of a certain group, e.g.,
SYSTEM. If you change parameter
values, but return the cursor to the first
field and scroll to another group
without pressing ENTER, the changes
are discarded and you will see the
message CONFIG LOST.
ENTER The cursor returns to the first field in the top
row. The second row displays shortly
CONFIG ENTER, then returns to the normal
display
7 Repeat steps 3 through 6 until values are
assigned to all the parameters in the group
SCROLL The second row shows the current selection
8 Repeat steps 1 through 7 until values are
assigned to all the parameters in the desired
groups
SCROLL The second row shows the current selection
