Connector Wiring
A-6
ASMi-450 Installation and Operation Manual
A.6 Ethernet Interface Connector
When the ASMi-450 is ordered with an Ethernet interface, the physical
interface is an RJ-45 connector wired in accordance with Table A-7.
Table A-7. Ethernet Interface Connector
Pin
Designation
Direction
Function
1
TxD+
To ASMi-450
Transmit Data - wire +
2
TxD-
To ASMi-450
Transmit Data - wire -
3
RxD-
From ASMi-450
Receive Data -
4
-
N/A
Not connected
5
-
N/A
Not connected
6
RxD+
From ASMi-450
Receive Data +
7, 8
-
N/A
Not connected
