ASMi-450 Control from the Control Port
ASMi-450 Installation and Operation Manual 4-5
4.3 Preparation for Use of Supervision Terminal
ASMi-450
Preparations
Internal Settings
See Section 2-4 for detailed information.
In general you must enter a password when you start a control session. If the
password is incorrect, the ASMi-450 will not respond. This can be corrected by
appropriate setting of the PSWD section of switch S1. Set the PSWD section of
switch S1 as follows:
OFF In this position, you can define your own password and node
address.
ON Set the switch section to ON to restore the default ASMi-450
password (ASMI), and change the node address to the default
value of 0. The change will be made after you turn the
ASMi-450 off for a short time, and then turn it back on.
Control Port Configuration
Configure the ASMi-450 control port as required. See Sections 3-5 through 3-7.
If the control port parameters are not correct, the ASMi-450 will not respond.
This can be corrected by appropriate setting of the DEF SP section of switch S1.
Set the DEF SP section of switch S1 as follows:
OFF In this position, you can define the desired control port
parameters.
ON Set the switch section to ON to restore the default control port
parameters. The change will be made after you turn the
ASMi-450 off for a short time, and then turn it back on.
Supervision
Terminal Configure the terminal for the same communication parameters you selected for
the ASMi-450 control port.
Connections Connect the control cable (coming directly from the terminal, or from the
modem used to connect the terminal) to the CONTROL DCE connector of the
ASMi-450. See Appendix A for cable wiring information.
Turn the control terminal on and when applicable, turn on the modems and the
other communication equipment used to connect the terminal to the ASMi-450.
