Rev.1.01 2007.02.16
RJJ10J1643-0101 86
RAPI_FTIOB Use FTIOB pin as input pin.
• Specifiable definition values when timer W is used (RAPI_TIMER_W specified)
(Count source) Specify one from { RAPI_TW_F1, RAPI_TW_F2, RAPI_TW_F4,
RAPI_TW_F8 }. The default value is RAPI_TW_F1.
(Operating states
set)
Specify one from { RAPI_TIMER_ON, RAPI_TIMER_OFF }. The default
value is RAPI_TIMER_OFF.
(Measurement
pulse)
Specify one from { RAPI_RISING_RISING, RAPI_FALLING_FALLING }.
The default value is RAPI_RISING_RISING.
(Interrupt) If overflow interrupt requests are enabled, specify RAPI_OVERFLOW. If
no interrupts are specified, “No interrupt request” is set.
• Specifiable definition values when timer Z is used (RAPI_TIMER_Z0 to RAPI_TIMER_Z1
specified)
(Count source) Specify one from { RAPI_TZ_F1, RAPI_TZ_F2, RAPI_TZ_F4,
RAPI_TZ_F8 }. The default value is RAPI_TZ_F1.
(Operating states
set)
Specify one from { RAPI_TIMER_ON, RAPI_TIMER_OFF }. The default
value is RAPI_TIMER_OFF.
(Measurement
pulse)
Specify one from { RAPI_RISING_RISING, RAPI_FALLING_FALLING }.
The default value is RAPI_RISING_RISING.
(Interrupt) If overflow interrupt requests are enabled, specify RAPI_OVERFLOW. If
no interrupts are specified, “No interrupt request” is set.
(Input pin) Specify one from { RAPI_FTIOA, RAPI_FTIOB }. The default value is
RAPI_FTIOA.
• Specifiable definition values when timer RC is used (RAPI_TIMER_RC specified)
(Count source) Specify one from { RAPI_TRC_F1, RAPI_TRC_F2, RAPI_TRC_F4,
RAPI_TRC_F8, RAPI_TRC_F32 }. The default value is RAPI_RC_F1.
(Operating states
set)
Specify one from { RAPI_TIMER_ON, RAPI_TIMER_OFF }. The default
value is RAPI_TIMER_OFF.
(Measurement
pulse)
Specify one from { RAPI_RISING_RISING, RAPI_FALLING_FALLING }.
The default value is RAPI_RISING_RISING.
(Interrupt) If overflow interrupt requests are enabled, specify RAPI_OVERFLOW. If
no interrupts are specified, “No interrupt request” is set.
(Input pin) Specify one from { RAPI_FTIOA, RAPI_FTIOB }. The default value is
RAPI_FTIOA.
(Clock for digital
filter)
Specify one from { RAPI_TRC_FILTER_F1, RAPI_TRC_FILTER_F8,
RAPI_TRC_FILTER_F32, RAPI_TRC_FILTER_F }. The default value is
RAPI_TRC_FILTER_F32.
• Specifiable definition values when timer RD is used (RAPI_TIMER_RD specified)
(Count source) Specify one from { RAPI_TRD_F1, RAPI_TRD_F2, RAPI_TRD_F4,
RAPI_TRD_F8, RAPI_TRD_F32, RAPI_TRD_F40M }. The default value
is RAPI_RC_F1.
(Operating states
set)
Specify one from { RAPI_TIMER_ON, RAPI_TIMER_OFF }. The default
value is RAPI_TIMER_OFF.
(Measurement
pulse)
Specify one from { RAPI_RISING_RISING, RAPI_FALLING_FALLING }.
The default value is RAPI_RISING_RISING.
