(Resolution)
Specify one from { RAPI_10BIT, RAPI_8BIT }. The default value is
RAPI_8BIT.
(Conversion
method)
Specify RAPI_WITH_SAMPLE_HOLD.
• Specifiable definition values when delayed trigger mode 1 is used
(RAPI_DELAYED_TRIGGER1 specified)
(Input pin)
Specify one from { RAPI_P0_GROUP, RAPI_P10_GROUP,
RAPI_P1P9_GROUP, RAPI_P9_GROUP }. The default value is
RAPI_P10_GROUP.
(Operating
frequency)
Specify one from { RAPI_FAD, RAPI_FAD2, RAPI_FAD3, RAPI_FAD4,
RAPI_FAD6, RAPI_FAD12 }. The default value is RAPI_FAD4.
(Resolution)
Specify one from { RAPI_10BIT, RAPI_8BIT }. The default value is
RAPI_8BIT.
(Conversion
method)
Specify RAPI_WITH_SAMPLE_HOLD.
(R8C)
RAPI_ONE_SHOT
Selects one-shot mode.
RAPI_REPEAT
Selects repeat mode.
RAPI_AN0
Uses AN0 pin for the analog input pin.
RAPI_AN1
Uses AN1 pin for the analog input pin.
RAPI_AN2
Uses AN2 pin for the analog input pin.
RAPI_AN3
Uses AN3 pin for the analog input pin.
RAPI_AN4
Uses AN4 pin for the analog input pin.
RAPI_AN5
Uses AN5 pin for the analog input pin.
RAPI_AN6
Uses AN6 pin for the analog input pin.
RAPI_AN7
Uses AN7 pin for the analog input pin.
RAPI_AN8
Uses AN8 pin for the analog input pin.
RAPI_AN9
Uses AN9 pin for the analog input pin.
RAPI_AN10
Uses AN10 pin for the analog input pin.
RAPI_AN11
Uses AN11 pin for the analog input pin.
RAPI_FAD
Sets the AD converter’s operating frequency to f
AD
.
RAPI_FAD2
Sets the AD converter’s operating frequency to f
AD
divided by 2.
RAPI_FAD4
Sets the AD converter’s operating frequency to f
AD
divided by 4.
RAPI_FOCOF
Sets the AD converter’s operating frequency to fOCO-F.
RAPI_10BIT
Sets the AD converter’s resolution to 10 bits.
RAPI_8BIT
Sets the AD converter’s resolution to 8 bits.
RAPI_AD_ON
Sets the AD converter to start operating in __CreateAD.
RAPI_AD_OFF
Sets the AD converter to stop operating in __CreateAD
RAPI_WITH_SAMPLE_
HOLD
Specifies that sample-and-hold action is applied.
RAPI_WITHOUT_
SAMPLE_HOLD
Specifies that sample-and-hold action is not applied.
