Step procedure (continued) – Paradyne BitStorm IP DSLAM 1900 User Manual
Page 78
2. BitStorm 1900 Installation and Testing
2-62
BitStorm 1900 Installation and Maintenance Guide
1900-A2-GN20-00
Step
Procedure
(continued)
Figure 2-13: Line/CPE and Voice Connections on the Filter Shelf for 10224 Modem Cards
Interconnect
Cable #1 IN
*Not Used
Dial Tone IN
from PBX/PSTN
EtherLoop
from BitStorm shelf
Dial Tone &
EtherLoop OUT
Interconnect
Cable #1 OUT
Amp Champ to
Dual Omni Grid Cable
part # 04-00007-10
Omni Grid to
Omni Grid Cable
part # 04-00008-18
J2
J1
J2
J2
J1
J2
J1
Female
Male
Male
J1
02-17185
