2. BitStorm 1900 Installation and Testing

2-54

BitStorm 1900 Installation and Maintenance Guide

1900-A2-GN20-00

Task 007: Installing the Data Network Connection with

an MIU

Use this procedure to connect the BitStorm 1900 to the Ethernet data
network using an MIU.

Requirements

This procedure requires the following:

Ethernet data network installed

Serial cable and DB9S to RJ-11 serial adapter (included)

PC with serial port to configure system

Two Category 5 crossover or straight cables terminated with RJ-45
connectors according to Table 2-1.

Step

Procedure

1.)

Connect one end of the RJ-45 (crossed) cable to the switch/router,

then route the other end to the 10 Base T-X port of MIU.

Table 2-1: Data Cable Selection for MIU Shelf Processor

MIU

Cable Requirements

Application

RS-232

RJ-11 cable (a DB9S to
RJ-11 serial adapter is
included)

To a PC (for configura-
tion only)

Ethernet Pass Thru

50-pin connector decapus
cable (DB50F) part #
04-00017-01, with 10
RJ-45 cables (included)

To Ethernet switch

10 Base-T X (top port)

(Management ports
must be connected)

RJ-45 straight cable, 6’
(included)

To a port on an interme-
diate switch or hub

NOTE: Switch or hub must

have connection to
EtherLoop network
router.

10 Base-T (bottom port)

Not used in this release

Not used in this release
