Appendix B. Cabling Specifications
B-122 BitStorm 1900 Installation and Maintenance Guide 1900-A2-GN20-00
Table B-1: AMP-Champ to Dual AMP-Champ Cable Specifications
Conn1 Color Code of
Cable 1 Conn2 Conn1 Color Code of
Cable 2 Conn3
1 BL/W 1 13 G/BK 1
26 W/BL 26 38 BK/G 26
2 O/W 2 14 BR/BK 2
27 W/O 27 39 BK/BR 27
3 G/W 3 15 S/BK 3
28 W/G 28 40 BK/S 28
4 BR/W 4 16 BL/Y 4
29 W/BR 29 41 Y/BL 29
5 S/W 5 17 O/Y 5
30 W/S 30 42 Y/O 30
6 BL/R 6 18 G/Y 6
31 R/BL 31 43 Y/G 31
7 O/R 13 19 BR/Y 13
32 R/O 38 44 Y/BR 38
8 G/R 14 20 S/Y 14
33 R/G 39 45 Y/S 39
9 BR/R 15 21 BL/V 15
34 R/BR 40 46 V/BL 40
10 S/R 16 22 O/V 16
35 R/S 41 47 V/O 41
11 BL/BK 17 23 G/V 17
36 BK/BL 42 48 V/G 42
12 O/BK 18 24 BR/V 18
37 BK/O 43 49 V/BR 43
