Appendix A. Installation Requirements
A-112 BitStorm 1900 Installation and Maintenance Guide 1900-A2-GN20-00
Installation Tools and Materials
The tools and materials required to install the BitStorm 1900 shelf
include the following:
• 4 bay mounting screws
• 1 medium Phillips-head screwdriver
• 1 cross-connect block matching the existing blocks used in the
facility MDF, such as Siemon R66, BIX, or AT&T 110 cross-
connect blocks
• 1 wiring punch-down tool intended for use with the cross-connect
block
• Cross-connect jumper wires (24 AWG, quantity varies) for tip/ring
connections
01-30036-01 Filter Card, 3RU 12 filters;
1 filter card per two 10306 cards
2 filter cards per 10224
04-00007-10 Champ to Dual Omni
Grid 2 per four 10306 cards
2 per 10224
04-00008-18 Omni Grid to Dual Omni
Grid 2 per 10224 w/filter shelf
04-00028-01 Omni Grid to Dual Omni
Grid 1 per two 10306 cards with filter shelf
03-00003-01 Air Baffle 1 per BitStorm 1900
01-00085-01 Bulk Pack 5 Fan Tray
Filters Replace every 6 months
(Required DC fan tray for NEBs
compliance)
DO NOT install a filter in an AC fan tray
– only the filter frame.
01-00084-01 DC Fan Tray 1 per BitStorm 1900 w/MIU
(An air filter must be installed to meet
NEBs)
01-00084-02 AC Fan Tray 1 per BitStorm 1900 w/MIU
(DO NOT install an air filter – only the
air filter frame.)
Table A-2: BitStorm 1900 Components (continued)
Part# BitStorm Component Rules/Capacity
