Appendix A. Installation Requirements
A-108 BitStorm 1900 Installation and Maintenance Guide 1900-A2-GN20-00
• The bay must be installed and secured in accordance with standard
telecommunications industry practices
• Use an Isolation Kit to isolate the bay from building structures and
outside elements for "in-building" installations (i.e., enterprise,
MDU, and MTU).
• The bay must be electrically grounded according to standard
telecommunications industry practices
BS1900 System Specifications
Table A-1, "BitStorm 1900 System Specifications" shows the power
specifications for the BitStorm 1900 shelf.
Table A-1: BitStorm 1900 System Specifications
BitStorm 1900 System Specifications
Description Front Mount
10306 Full
1
Front Mount
10224 Full
2
Lines Per Chassis 60 Lines, 10 Megabit 240 Lines, 10 Megabit
Weight 50 lbs. 46 lbs.
Height 12.1875” 12.1875”
Width 12” 12”
Required Rack Units 13 13
Depth 12” 12”
Cabled Depth 17.5” 17.5”
Cabled Ear to Front (Front Mount) 4” 4”
Cabled Ear to Front (Mid Mount) 7.75” 7.75”
Cabled Ear to Back (Mid Mount) 13.5” 13.5”
Cabled Ear to Back (Mid Mount) 9.75” 9.75”
Humidity (Non-Condensing) 1% to 90% 1% to 90%
Ambient Temp. Rating
5
o
C to 40
o
C 5
o
C to 40
o
C
Altitude -200 to 13,123’ -200 to 13,123’
