2. BitStorm 1900 Installation and Testing
2-42 BitStorm 1900 Installation and Maintenance Guide 1900-A2-GN20-00
Task 003: Installing the BS1900 and Filter Shelves
Use this procedure to install the BitStorm 1900 modem shelf and filter
shelf.
NOTE: The filter shelf is not required in data-only applications.
Requirements
This procedure requires the following:
• Equipment bay with enough space available installed, secured, and
electrically grounded according to standard industry practice
(specifications for a suitable bay are described in the Appendix A
section "Bay Requirements and Specifications," on page 107).
• Installation hardware kit supplied with shelf
• Phillips-head screwdriver (#1 or #2)
! WARNING: POSSIBLE EQUIPMENT DAMAGE! DO NOT
rest objects such as tools or anyhting else
on top of the BitStorm 1900 shelves. The
mounting fasteners can only support the
weight of the shelf. Additional weight may
weaken the fasteners.
