1. BitStorm 1900 IP DSLAM
1900-A2-GN20-00 BitStorm 1900 Installation and Maintenance Guide 1-13
Table 1-3: System Power Specifications with 10306 CO Modem
* Configuration assumes 10 modem cards are used.
10306 CO Modem IP Multicast Operation
An optional feature of the 10306 CO modem card is the ability to pass
IP Multicast traffic only to the subscribing port. The 10306 modem
card functions as a multi-layer switch and supports IGMP v1/v2 when
connected to the MIU (Management Interface Unit) card via the 100
Base-T Ethernet backplane connection. The 10306 modem creates Port
Table data when a client joins a multicast group and forwards the IGMP
message upstream through the MIU to an IGMP-enabled Switch. When
the IP Multicast data is streamed back to the 10306, it replicates and
forwards the IP Multicast streams ONLY to the ports with subscribing
clients.
Power Bit Storm 1900
Configuration
Modem
Cards
# Lines Power
(Watts)
Watts
Per
Line
Watts
w/Fan
Tray
Max
Current
DC 260 W DC power supply 10306* 60 260 4.4 305 6.4
AC 260 W AC power supply 10306* 60 230 3.8 335 3.1
! WARNING: POSSIBLE EQUIPMENT DAMAGE! AC Fan
Trays are shipped with an air filter frame. To
ensure proper airflow, the frame must be
installed. DO NOT install an air filter for the
AC Fan Tray, only the frame.
