1. BitStorm 1900 IP DSLAM
1-28 BitStorm 1900 Installation and Maintenance Guide 1900-A2-GN20-00
Fan Tray -48 V DC
Figure 1-10: Fan Tray -48 V DC (Part #: 01-00084-01)
Table 1-6: Power Specifications for the DC Fan Tray
Audible Alarm Fan Failure LEDs ON/OFF
02-17171
Fan Tray -48 V DC Specifications
Operating Temperature
0
o
C to 40
o
C (0
o
F to 104
o
F)
Storage Temperature
-40
o
C to 70
o
C (-40
o
F to 158
o
F)
Certifications UL 60950, cUL, NEBS Level 3 CE
Power Consumption 45W
Dimensions 3.5” x 18” x 13”
NEBS Air Filter Change every 6 months
Cord 14-gauge stranded cable (not included)
-48 V DC Supply Fuse 2 AMP, -48 V DC Supply Fuse
Power Bit Storm 1900
Configuration
Modem
Cards
# Lines Power
(Watts)
Watts
per line
Watts
w/fan tray
Max
current
DC DC Fan Tray n/a n/a 45 n/a n/a .9
