Paradyne BitStorm IP DSLAM 1900 User Manual
Page 133
Appendix B. Cabling Specifications
1900-A2-GN20-00
BitStorm 1900 Installation and Maintenance Guide
B-117
Figure B-2: Cabling – Filter 66-Block with 10306 Modem Cards
10306
10306
10306
10306
2 RU FAN
2 RU AIR BAFFLE
2 RU FAN
2 RU AIR BAFFLE
2 RU FAN
2 RU AIR BAFFLE
2 RU FAN
2 RU AIR BAFFLE
02-17195
*Only one Filter 66-Block
and one set of cables
are shown. 60 total lines are
possible per BitStorm 1900
with 10306 cards
Lines 1-12 EtherLoop OUT
Amp Champ to
Dual Omni Grid Cable
part # 04-00007-10
24 Lines of
Dial Tone
and EtherLoop™
Lines 13-24 EtherLoop OUT
Amp Champ to
Dual Amp Champ Cable
part # 04-00029-01
24 Lines of
Dial Tone
