Chapter 3: AT Commands Reference
April 15, 2008 G24-L AT Commands Reference Manual 3-133
AT+CBAUD?
+CBAUD: 57600
OK
AT+CBAUD=?
+CBAUD: (0-13,300,600,1200,2400,4800,9600,19200,38400,57600,115200,230400,460800)
OK
+IPR, Local Terminal/G24-L Serial Port Rate
This command is responsible for setting and saving the request baud rate. This numeric
extended-format parameter specifies the data rate at which the G24-L accepts commands.
Specifying a value of 9 disables the function and allows operation only at rates automatically
detectable by the G24-L. The specified rate takes effect following the issuing of any result
code(s) associated with the current command line.
The value specified is the rate in bits per second at which the terminal-G24-L interface
operates, for example, 19200 or 115200. The rates supported by the G24-L are
manufacturer-specific. However, the +IPR parameter permits setting any rate supported by the
G24-L during online operation.
The UART is configured to rates of 300, 600, 1200, 4800, 9600, 19200, 38400, 57600, 115200,
230400, 460800 bits per second according to the parameters of the +IPR command.
Using AT+IPR= with a value other than 9 and 0 disables the auto baud rate
detection feature. The entered baud rate is stored in the G24-L and is restored after power up.
Notes: +IPR is similar to +CBAUD, but with the ability to save.
Command Type Syntax Response/Action
Set AT+IPR=
AT+IPR=
OK
or:
ERROR
Read AT+IPR? +IPR:
Test AT+IPR=? +IPR: (list of supported s)
