The following table shows the +MIOD parameters.
The following table shows the keypad GPIOs.
Table 3-96: +MIOD Parameters
Description
Selected pins for the action invoked. This is a binary vector in which each bit points to
pin number. Vector size is 8.
0
Not selected
1 Selected pin (default)
GPIO pin operation mode.
0
Output (level only)
1 Input (level mode)
This is a binary vector in which each bit shows the operation mode of pin. Data vector
size is 8.
0
Output (level only)
1 Input (level mode)
The default value:
On Power Up - as previously saved in FLEX bytes.
Before set command first used - 1. (This means that all lines are configured as Input
before set command first used).
This is a binary vector in which each bit shows the physical value of pin. Data vector
size is 8.
0
Physical low signal.
1 Physical high signal (default).
The default value:
On Power Up - as previously saved in FLEX bytes.
Before set command first used with and =0, or after +MIOD
without and before +MIOD command used - 1.
Table 3-97: Keypad GPIOs
GPIO
Name
70 PIN
connector,
PIN#
GPIO
Number
GPIO1 28 1
GPIO2 30 2
GPIO3 32 3
GPIO4 34 4
GPIO5 36 5
GPIO6 38 6
GPIO7 40 7
GPIO8 42 8
