GPRS
3-278 G24-L AT Commands Reference Manual April 15, 2008
Example
+MIPOPEN: 1 2 3 4 //All sockets closed
+MIPOPEN: 1 3 4 //Socket 2 opened
The following table shows the +MIPOPEN parameters.
Note: Motorola does not recommend using port numbers below 1024. These numbers are
defined to be reserved for operating systems.
Read AT+MIPOPEN? +MIPOPEN:[]
for each socket that can be opened
or:
+MIPOPEN 0
if there are no free sockets.
The Read command
returns the numbers of
the sockets that can be
opened.
Test AT+MIPOPEN=? +MIPOPEN: (list of supported
s),(list of supported
s),(list of
supported<"Destination IP">s),
(list of s),(list of
supported s)
Table 3-196: +MIPOPEN Parameters
Description
Socket ID A unique number that identifies a connection (provided by the terminal application).
0
Invalid socket number
1,2,3,4 Valid socket number
Source Port Port of source site.
Port range: 1-65535 (decimal digits)
Destination
Address IP: IP of the destination site in the format "AAA.BBB.CCC.DDD". The range of each
octant is 0-255. The value can be written in 1, 2, or 3 digits.
Host name: Host-name of destination site. The host-name do not validate, except the
maximum length (255 characters), the host-name convention should meet the rules as
describe in RFC-1035 section: 2.3. Conventions.
Destination
Port Port of destination site.
Port range: 1-65535 (decimal digits).
Protocol Type of protocol stack.
0
TCP
1 UDP
State State of socket or error indication.
0
Inactive
1 Active
Command Type Syntax Response/Action Remarks
