SuperTrak66™ User's Manual Chapter 5
- 88 -
5.11 Enclosure Functions
The “EnclosureX” icon(s) represent the server-level monitoring capabilities
of SuperCheck. From this icon, users may choose to enable alerting alarms
during rebuilding and synchronizing of arrays. In addition, they may monitor
enclosure status if the user has mounted the hard drives inside optional
FastSwap66 or SuperSwap66 “hot” swap boxes (one drive per box) manufactured
by Promise. FastSwap66 permits monitoring fan and housing temperature status.
SuperSwap66 allows monitoring fan, temperature, and power.
Enabling Rebuild/Synchronization Beeper
System administrators may wish to enable or disable an audible beeper alert that
the SuperTrak66 emits during rebuild of drives and synchronization of drives. The
beeper warns the admin that the system is in a degraded status during these
processes and alerts admin when the process is complete.
1) Double-click the Enclosure icon in Tree View.
2) In the Information View (see Figure 69), check or uncheck the
Rebuild/synchronization Beeper box.
Viewing Enclosure Object icons
Double-clicking on the “Enclosure” icon in Tree View will display “fan” and
“temp” icons in the Object View associated with that enclosure. Clicking on any of
the Object View icons will display an Information View nearly identical to the
“Enclosure” Information View. The only difference is that the Object View will not
appear.
Figure 68: Enclosure Object View
