SuperTrak66™ User's Manual Chapter 5
- 79 -
5.7 I
2
O RAID Functions
The “I
2
O RAID” icon(s) in the Tree View represents the I
2
O component
installed on a Message Agent. Through here, you can identify model
information and hardware/firmware versions.
Viewing I
2
O RAID Object icons
Double-clicking on an “I
2
O RAID” icon generates the “IOPx” icon in the Object
View (see below).
Figure 58: I
2
O RAID Object View
Information View
In the Information View (see below), two fields are displayed: “Type” and “Version
information” which reflect the model number, name of the controller installed in the
system, and version information concerning the hardware and firmware. No fields
may be modified here.
Figure 59: I
2
O RAID Information View
