SuperTrak66™ User's Manual Chapter 5
- 57 -
Using SuperCheck Toolbar
Figure 35: Toolbar icons
Toolbar icons and their associated functions are available depending on which of
the items in the Tree View is highlighted as described in the descriptions below.
New Server: available when the Console icon is active. It allows the user to
create a New Server on the SuperTrak66 system. The user must have “User
Account Rights” (see p. 59 for details).
Connect Server: available when a particular Server icon is active. It allows
the user to recognize the Server on the SuperTrak66 system. The user must have
“User Account Rights” (see p. 61 for details).
Disconnect Server: available when the Server icon is active. It allows the
user to take the Server offline from the SuperTrak66 system. The user must have
“User Account Rights”. Disconnect is the only proper way to shut down the
SuperTrak66 server in order to perform physical maintenance. This also logs off the
Server from being recognized by any other SuperCheck monitoring utility online
(see p. 61 for details).
Rebuild Array: available when an Array icon for a RAID Level 1, 3, or 5 is
active. This begins the process of restoring data to a replaced drive from remaining
drives in the array. The user must have “User Account Rights” (see p. 91 for
details).
Synchronize Array: available when an Array icon for a RAID 1 or 0+1 level
array is active. This allows user to write data from primary mirrored drive(s) to
secondary mirrored drive(s) to assure both have identical data as a maintenance
procedure. The user must have “User Account Rights” (see p. 94 for details).
Delete Array: available when an Array icon is active. This allows the user to
delete the array from the SuperTrak66 system The user must have “User Account
Rights” (see p. 90 for details).
