SuperTrak66™ User's Manual Chapter 7
- 112 -
7.3 SuperTrak66 BIOS Error Messages
On bootup, the SuperTrak66 BIOS will initialize. Should an error be detected, the
following messages will appear on screen and the bootup process halted.
Message:
No Array is defined…
Cause: Either no drives are detected, or the drives detected are not
assigned to an array. The SuperTrak66 BIOS only provides int 13h
support for defined arrays. If there are no drives detected, or the
detected drives are not assigned to an array, then the BIOS has
nothing to support for int 13h. You must use the SuperBuild utility
to define an array using drives attached to the SuperTrak66.
Message:
Problem is detected with Array : X
Cause: There is a critical or offline array. A fault tolerant array will require
one of the drives to be replaced (if a hot spare has not already
been invoked). A non-fault tolerant array will be pulled completely
offline, and is no longer accessible.
