A-61133 March 2003 2-1
2 Getting Started
The main window This chapter describes the menus, toolbars and Control Panel that are
available when using the Kodak i7300 Scanner Application Software.
Some menu options, when selected, will perform the action
immediately. Other menu options, those options followed by three dots
(…), will display a dialog box. If an option on the menu is checked (
√
),
the option is enabled. More information regarding dialog boxes and how
to use them can be found in Chapter 3, Using the Software.
The main window contains the following elements:
•
Title bar
•
Menu bar
•
Image display pane
•
Image Retrieval keypad
These elements can be optionally displayed:
•
Toolbar
•
Control Panel
•
Status bar
•
Documents/Folder pane
•
Thumbnail pane
Status bar
Documents/Folder pane Image display pane
Title bar Menu bar Toolbar
Thumbnail pane
Control Panel
Image Retrieval
keypad
