5-10 A-61133 March 2003
Changing the starting register:
1. Select CAR>Registers>View. The CAR Registers dialog box will
be displayed:
2. Highlight the register from the list box where you want to start at and
double-click the mouse button.
3. Click Start.
4. Click OK to close the CAR Registers dialog box.
CAR monitor The CAR Monitor option allows you to stop and resume execution of
CAR commands to perform image processing functions or use the
menu functions. When you select CAR>Monitor the CAR Monitor
dialog box is displayed:
Display Time slider bar

allows you to slow down or speed up CAR
command transmission.
Stop/Resume

when selected, will complete the current CAR
command, display the image and stop. Select Resume to continue.
Close

closes the CAR Monitor dialog box.
Extended

when enabled, will expand the CAR Monitor dialog box.
