123
4
Press the [Connect] button to connect to the
camera and start audio transmission
● Connection status with the camera is displayed in the
[Status] area of the [Status Information] list. Press the
[Connect] button and audio sound that input to [AUDIO
IN 1] terminal of this unit will be transmitted to the
cameras that are displayed as
AConnectedB.
● If ADisconnectedB appears, check the network between
this unit and the camera, IP address of the camera,
and the power of the camera. If [Authentication failed]
appears, repeat procedures on the [Event Audio
Setting] screen to register the password of the camera
for which the [Authentication failed] message is
displayed.
[Password] (A Page 126)
5
Press the [Disconnect] button to disconnect the
camera
Memo :
● Cameras that are not registered in [Camera Record
Setting] of the main menu cannot be selected.
● If the audio setting of the camera is set to the half duplex
mode, you will not be able to hear audio sound from the
camera when in the
AConnectB status.
● If you are sending the microphone sound to a camera for
which an event audio has been set, the audio playback
function that is associated with an event will be disabled
during microphone sound transmission, and priority is
given to the microphone sound transmission.
● You can also operate the [Connect] and [Disconnect]
button from the alarm terminal on the rear panel. In this
case, select the alarm terminal to be used for control with
[Push To Talk] under [Event Audio Setting]. An alarm
input triggers an action equivalent to the [Connect] button,
and canceling the alarm is equivalent to the action when
you pressed the [Disconnect] button. Control of the
[Connect] and [Disconnect] is valid only when these
buttons are enabled.
Note :
● If you are configuring the settings or performing an audio
playback test in the [Camera Record Setting] or [Event
Audio Setting] of the main menu, do so after you have
closed this dialog box.
● If the performance meter lights up in yellow or red, the
microphone sound may be interrupted. To make sure that
audio sound is successfully transmitted, perform
operations such as temporarily stopping the recording
operation so that the performance meter does not light up
in yellow or red. [Performance Meter] (A Page 23)
