Verifying RPM Services
Purpose Verify that the RPM configuration is within the expected values.
Action From configuration mode in the CLI, enter the show services rpm command.
user@host# show services rpm
probe test {
test customerA {
probe-type icmp-ping;
target address 192.178.16.5;
probe-count 15;
probe-interval 1;
hardware-timestamp;
}
test customerB {
probe-type icmp-ping-timestamp;
target address 192.178.16.5;
probe-count 15;
probe-interval 1;
hardware-timestamp;
}
test customerC {
probe-type udp-ping;
target address 192.178.16.5;
probe-count 15;
probe-interval 1;
destination-port 50000;
hardware-timestamp;
}
}
Meaning The output shows the values that are configured for RPM on the Services Router.
Verifying RPM Statistics
Purpose Verify that the RPM probes are functioning and that the RPM statistics are within
expected values.
Action From the J-Web interface, select Monitor>RPM. From the CLI, enter the show services
rpm probe-results command.
user@host> show services rpm probe-results
Owner: customerA, Test: icmp-test
Probe type: icmp-ping-timestamp
Minimum Rtt: 312 usec, Maximum Rtt: 385 usec, Average Rtt: 331 usec,
Jitter Rtt: 73 usec, Stddev Rtt: 27 usec
Minimum egress time: 0 usec, Maximum egress time: 0 usec,
Average egress time: 0 usec, Jitter egress time: 0 usec,
Stddev egress time: 0 usec
Minimum ingress time: 0 usec, Maximum ingress time: 0 usec,
Average ingress time: 0 usec, Jitter ingress time: 0 usec,
Stddev ingress time: 0 usec
Probes sent: 5, Probes received: 5, Loss percentage: 0
Owner: customerB, Test: http-test
Target address: 192.176.17.4, Target URL: http://customerB.net,
Probe type: http-get
