■ Monitoring RSVP Session Information on page 133
■ Monitoring MPLS RSVP Interfaces Information on page 134
Monitoring MPLS Interfaces
To view the interfaces on which MPLS is configured, select
Monitor>MPLS>Interfaces, or enter the following CLI command:
show mpls interface
Table 64 on page 131 summarizes key output fields in the MPLS interface information
display.
Table 64: Summary of Key MPLS Interface Information Output Fields
Additional Information Values Field
Name of the interface on which MPLS is
configured. Interface
State of the specified interface: Up or Dn (down). State
Administratively assigned colors of the MPLS link
configured on the interface. Administrative groups
Monitoring MPLS LSP Information
To view all label-switched paths (LSPs) configured on the Services Router, including
all inbound (ingress), outbound (egress), and transit LSP information, select
Monitor>MPLS>LSP Information, or enter the following CLI command:
show mpls lsp
Table 65 on page 131 summarizes key output fields in the MPLS LSP information
display.
Table 65: Summary of Key MPLS LSP Information Output Fields
Additional Information Values Field
Information about LSPs on the inbound router.
Each session has one line of output. Ingress LSP
MPLS learns this information by querying RSVP,
which holds all the transit and outbound session
information. Information about the LSPs on the outbound
router. Each session has one line of output. Egress LSP
MPLS learns this information by querying RSVP,
which holds all the transit and outbound session
information. Number of LSPs on the transit routers and the
state of these paths. Transit LSP
Destination (outbound router) of the session. To
Using the Monitoring Tools ■ 131
Chapter 7: Monitoring the Router and Routing Operations
