Table 62: Summary of Key CoS Rewrite Rules Output Fields (continued)
Additional Information Values Field
Rewrite rules are applied to CoS values in
outgoing packets based on forwarding class
and loss priority setting. Forwarding class that in combination with
loss priority is used to determine CoS values
for rewriting. Forwarding Class
Loss priority that in combination with
forwarding class is used to determine CoS
values for rewriting. Loss Priority
Value that the CoS value is rewritten to. Rewrite CoS Value To
Monitoring CoS Scheduler Maps
To display assignments of CoS forwarding classes to schedulers, select Monitor>Class
of Service>Scheduler Maps in the J-Web interface, or enter the following CLI
command:
show class-of-service scheduler-map
Table 63 on page 129 summarizes key output fields for CoS scheduler maps.
Table 63: Summary of Key CoS Scheduler Maps Output Fields
Additional Information Values Field
For details, click the plus sign (+). Name of a scheduler map. Scheduler Map
Index of a specific object—scheduler maps,
schedulers, or drop profiles. Index
Name of a scheduler. Scheduler Name
Forwarding classes this scheduler is
assigned to. Forwarding Class
Configured transmit rate of the scheduler
in bits per second (bps). The rate value can
be either of the following:
■ A percentage—The scheduler receives
the specified percentage of the total
interface bandwidth.
■ remainder —The scheduler receives the
remaining bandwidth of the interface
after allocation to other schedulers.
Transmit Rate
Rate limiting configuration of the queue:
■ none —No rate limiting.
■ exact —The queue transmits at only the
configured rate.
Rate Limit
Using the Monitoring Tools ■ 129
Chapter 7: Monitoring the Router and Routing Operations
