Table 71: Summary of Key Stateful Firewall Filters Output Fields (continued)
Values Field
Direction of the flow: I (input) or O (output). Direction
Number of frames in the flow. Frames
Monitoring Firewall Intrusion Detection Services (IDS)
To view intrusion detection service (IDS) information for stateful firewall filters, select
Monitor>Firewall>IDS Information. Click one of the following criteria to order the
display accordingly:
■ Bytes (received bytes)
■ Packets (received packets)
■ Flows
■ Anomalies
To limit the display of IDS information, type or select information in one or more of
the Narrow Search boxes listed in Table 72 on page 139, and click OK.
Table 72: IDS Search-Narrowing Characteristics
Entry or Selection Narrow Search Box
Type a destination address prefix to display IDS information for only that prefix. Destination Address
Select one of the following:
■ Destination—Displays information for an address under attack.
■ Pair—Displays information for a suspected attack source and destination pair.
■ Source—Displays information for an address that is a suspected attacker.
IDS Table
Select a number between 25 and 500 to display only a particular number of entries. Number of IDS Entries to
Display
Type a number to display events with only that number of bytes, packets, flows, or
anomalies—whichever you selected to order the display. For example, to display all events
with more than 100 flows, click Flows and then type
100 in the Threshold box.
Threshold
Select a service set to display information for only the set. Service Set
Alternatively, enter the following CLI show commands:
■ show services ids destination-table
■ show services ids source-table
■ show services ids pair-table
Using the Monitoring Tools ■ 139
Chapter 7: Monitoring the Router and Routing Operations
