Chapter 7 - Troubleshooting the Impulse
7-3
Limits Tables
Velocity Limits at ALL RESOLUTIONS are:
Min = 0.00002 RPS
Max = 100 RPS
Acceleration and Deceleration Limits are the following:
6 LED flashes
(Over Temperature Fault) Internal Fan or Heatsink Tunnel is
clogged or restricted (internal temp.
has exceeded 68° C (154° F). Remove obstruction (clean by blow-
ing shop air through the tunnel.
Ambient air in cabinet is too hot. The Impulse can produce 20 Watts
of heat. If multiple units are installed
next to each other, the cabinet must
be adequately ventilated to remove
heat.
The cooling fan is not turning. Cooling fan is inoperable. Return unit
to factory for repair.
7 LED Flashes
(EEPROM Checksum Fault) At power-up the drive tests the in-
tegrity of its non-volatile memory by
computing a checksum. This fault
indicates an abnormal or defective
condition in the drive.
An error occured during download
or EEPROM write.
The fault can be cleared by issuing a
default configuration from Applica-
tion Developer and then reconfigur-
ing the drive for the target motor. If
the fault recurs, the drive is definitely
defective. The user should not be
able to cause this fault inadvertently
through any combination of com-
mands or actions.
Symptom Possible Causes Possible Remedies
Step
Resolution
Accel/ Decel Limits
Min (RPS 2 ) Max (RPS 2 )
200 0.001 1000000
400 0.001 500000
1000 0.001 200000
2000 0.001 100000
5000 0.001 40000
10000 0.001 20000
18000 0.001 11110
25000 0.001 8000
25400 0.001 7874
25600 0.001 7812
36000 0.001 5555
50000 0.001 4000
50800 0.001 3937
100000 0.001 2000
