Chapter 5 - Configuring Impulse with an IDC Keypad
5-9
Using the HELP Menu
Versions
• Press the HELP > VERSN (F2) for access to Operating
System, Hardware, and Keypad versions (see examples on
the right).
• Press F1, F2, or F3 for respective version displays.
• Press the ESC key to exit the HELP menu.
Status
• Press HELP > STATUS for I/O configurations, current
drive status, and the operating history of the drive.
• Press I/O to check the configuration of four discrete inputs
and one output.
• Press DRIVE for current drive status. The example shows
no fault condition.
• Press HISTRY for the following operating histories: num-
ber of hours in operation, number of power cycles, and last
eight drive faults.
• Press HR_OP for the total number of hours the Impulse
has been in operation.
• Press PWR_CY for the number of times power has been
cycled.
• Press FAULT to look scroll through the last eight (8) drive
faults. Stored Fault #1 is the most recent fault.
HELP
−−−−−− −−−−−− −−−−−− −−−−−−
HELP
−−−−−− −−−−−− −−−−−− −−−−−−
START VERSN STATUS
VERSIONS
OPSYS HDRWAR KPAD
OpSystem Version
vXXX
Hardware Version
AMP: E0 I/O F0
Keypad Version
vXXX
STATUS
I/O DRIVE HISTRY
In1 In2 In3 In4 Out1
OFF OFF OFF OFF OFF
System is Enabled
FAULT: ✻✻✻✻
OPERATING HISTRY
HR _OP PWR_CY FAULT
Hours Operation
XXX.XX
Num Power Cycles
XXX
↑↑↑↑
Stored Fault #1
↓↓↓↓
Overcurrent (example)
